Project Description

Telsun Farming Tractor Wheel Specifications

Wheel size Telsun Part No. Bolt hole No. Bolt hole dia Center hole P.C.D. Offset Permitted tyre size
3.00DX14 F30014-1 5 15.5 110 140 20 4.00-14
3.00DX16 F30016-1 4 15.5 91 127 10 4.00-16
F30016-2 4 17 92.2 127 15
4.00EX15 F40015-1 4 20 110 152 20 6.00-15
4.00EX16 F40016-1 5 20 94 140 25 6.00-16
4.50EX16 F45016-1 6 13 110 140 60 6.50-16
F45016-2 5 20 135 175 25
F45016-3 6 18.5 117.5 152.4 42
5.00FX16 F50016-1 6 19 117.7 152 0 6.50-16
5.50FX16 F55016-1 6 17 141 180 30 7.50-16
5.50FX20 F55020-1 6 15.5 102 161 0 7.50-20
6.00FX20 F60020-1 6 17 141 180 30 7.50-20
W7X20 FW720-1 6 15 146 165 70 8.3-20
W7X24 FW724-1 6 15 130 165 30 8.3-24
W10X20 FW1020-1 6 15 130 165 70 11.6-20
W7X26 FW726-1 8 17 128 165 ACCORDI NG TO CUSTOM ER’S REQUIRE
-MENTS
8.3-26
W8X24 FW824-1 6 15 130 165 9.5-24
W8X32 FW832-1 8 17 291 330 9.5-32
FW832-2 6 20 180 230
9.00X15 F90015-1 5 18.5 157 206 10.00-15
9.00X15.3 F900153-1 6 17 161 205 10.00-15.3
F900153-2 6 21.5 161 205
W9X18 FW918-1 8 17.5 152.4 203.2 12.5-18
W10X24 FW1024-1 6 20 120 165 11.2-24
W10X28 FW1028-1 8 17 151 203.2 11.2-28
FW1028-2 6 20 180 230
W10X32 FW1032-1 8 19 152.6 203.2 11.2-32
W11X26 FW1126-1 8 19 152.6 203.2 12.4-26
W11X28 FW1128-1 8 19 152.6 203.2 13.6-28
W11X38 FW1138-1 8 19.5 180 223 12.4-38
W12X24 FW1224-1 8 17 291 330 13.6-24
W12X30 FW1230-1 8 19 152.6 203.2 13.6-30
W12X38 FW1238-1 8 19 152.6 203.2 13.6-38
W13X28 FW1328-1 8 19 150 200 14.9-28
W13X30 FW1330-1 8 19 150 200 14.9-30
W14X24 FW1424-1 12 18 500 534 15.0-24
W14X28 FW1428-1 10 23 281 335 15.5-28
W14LX30 FW1430-1 8 19.5 150.1 203.2 15.5-30
W15X28 FW1528-1 10 23 281 335 16.9-28
W15LX38 FW1538-1 8 19.5 150.1 203.2 16.9-38
W15LX30 FW1530-1 8 19 152.6 203.2 16.9-30
W15LX34 FW1534-1 8 19.5 180 223 16.9-34
W16LX38 FW1638-1 8 21 240 295 18.4-38
W18LX38 FW1838-1 8 21 240 295 20.8-38
W20X26 FW2026-1 8 17 291 330 20.1-26
DW12X38 FDW1238-1 8 20.5 152.4 203.2 69.5 13.6-38

Above data is a bit part of the farming wheel sizes, for more sizes,  email us please!
